Product Configuration1

Intel® Core™ Ultra 5 225H
Intel® Arc™ Graphics
32GB LPDDR5X 8400MT/s
1TB PCIe 4.0 SSD*
Star Gray

Product Configuration2

Intel® Core™ Ultra 7 255H
Intel® Arc™ Graphics
32GB LPDDR5X 8400MT/s
1TB PCIe 4.0 SSD*
Star Grey

Processor 1

Intel® Core™ Ultra 7 255H
Efficiency core maximum turbo frequency 4.4GHz
Performance core maximum turbo frequency 5.1GHz
16-core 16-thread processor
L3 cache 24MB

Processor 2

Intel® Core™ Ultra 5 225H
Efficiency core maximum turbo frequency 4.3GHz
Performance core maximum turbo frequency 4.9GHz
14 core 14 thread processor
L3 cache 18MB

Network

2*2 MIMO dual antenna
Support 802.11ax (Wi-Fi6) network protocol, compatible with 802.11 a/b/g/n/ac
Support 2.4GHz, 5GHz dual-band
Support Bluetooth 5.2

Display

16" display, 16:10 aspect ratio
3072 × 1920 resolution
Max 165Hz supports DRR dynamic refresh rate switching (60/120Hz)
500nits Typ brightness, 100% DCI-P3 color gamut
Full DC dimming, support Dolby Vision*
Passed German Rhine TÜV hardware-level low blue light certification, German Rhine TÜV flicker-free certification

Camera and input devices

Front camera 1080P
Fingerprint power button
Full-size keyboard, four keyboard backlight modes, 1.3mm key travel
150mm × 95mm, large-size touchpad

Audio

Speakers: 2 × 2W
3 Microphones
Audio software: Dolby Atmos*

Interfaces

USB-A 3.2 Gen1 × 2
USB-C full function × 1
Thunderbolt 4 × 1
HDMI 2.1 TMDS × 1*
3.5mm headphone and microphone jack × 1

Dimensions and weight: Length

354.98mm × Width 247.95mm × Thin to about 15.9mm*
Light to about 1.88kg*
Opening and closing angle: 170° ± 5°* (theoretical design value, plus or minus 5° in actual measurement is within a reasonable range)

Battery power

Typical capacity: 99Wh*
140W GaN adapter
