Product Details
Souria 22 inches Smart Magic Mirror Waterproof TV for Bathroom Hotel DTV Tuner WiFi Bluetooth Built-in Apps Store ATSC DVB-T T2




Black color when turned on or off:

White color when turned on or off:





3 optional methods provided to accommodate TV installations
Option 1: In-wall with Embedded Bracket
Option 2: On-wall with Embedded Bracket
Option 3: On-wall with VESA Bracket




INSTALLATIONS:
Option 1: In-wall with Embedded Bracket
-
Create an opening within the chosen area of the wall according to the Embedded Bracket outlines. Leave enough space for the cables and adapter.
-
Set up power and signal circuit and the outlet.
-
Place the Embedded Bracket into the recess and use the pilot holes to drill into the wall.
-
Place the raw plugs into the holes that have been drilled and screw the Embedded Bracket into position.
-
Organize the cables and offer the TV up to the Embedded Bracket that is fixed within the wall.
-
Line up the 4 x metal lugs located on the sides of the TV case with the 4 x channels located within the Embedded Bracket and simply push the TV into situ.
Option 2: On-wall with Embedded Bracket
-
Drill holes within the chosen area of the wall according to the Embedded Bracket outlines.
-
Place the raw plugs into the holes and screw the Embedded Bracket into position so it is attached to the wall.
-
Set up power and signal circuit and the outlet.
-
Simply offer the TV up to the Embedded Bracket that is fixed on the wall.
-
Line up the 4 x metal lugs located on the sides of the TV case with the 4 x channels located within the Embedded Bracket and simply push the TV into situ.

ACCESSORIES:
1. Embedded Bracket
2. Power Adapter (Input: AC 100V – 240V, Output: DC 12V, 5A)
3. Waterproof Remote Control (Without Button Cell Battery Supplied, IP68 Waterproof)
4. User Manual
5. Installation Kit (6 sets)
PACKAGING:
